EHR Integration for Healthcare Websites: A Practical Guide for IT Leaders

Healthcare websites generally connect to an EHR through one of three approaches. The correct choice depends on the EHR, clinical workflow, required data, and whether the integration is patient facing or backend focused.

FHIR, or Fast Healthcare Interoperability Resources, provides structured resources and APIs for exchanging healthcare information.

For a patient portal, that can mean retrieving resources such as Patient, Observation, Encounter, MedicationRequest, Appointment, or DiagnosticReport through an API.

Since January 1, 2023, all certified EHR platforms have been required to expose a standardised FHIR API for patient and population services under the ONC Cures Act Final Rule.

The practical advantage is consistency. Your development team can work against defined resource structures rather than building a completely different data exchange mechanism for every EHR.

That does not mean every FHIR integration works identically. Implementation guides, supported resources, scopes, authentication requirements, and vendor configurations still require careful review.

If your project includes a patient portal, the integration architecture should be defined alongside your patient portal development requirements rather than added after the interface is designed.

Our web focused guide to FHIR API integration covers the frontend implications in greater detail, including authentication, resource queries, and handling FHIR responses.

HL7 v2 remains important across hospital environments, particularly for internal clinical and operational data exchange.

Unlike a typical patient facing FHIR API request, HL7 v2 commonly works through messages exchanged between systems. Messages can communicate events such as admissions, discharges, transfers, orders, and results.

That makes HL7 v2 useful for backend integration, but it often requires an integration engine or middleware layer before information reaches a modern web application.

For a new patient facing website, using HL7 v2 directly from the browser would generally create unnecessary complexity. A controlled backend service can instead translate required information into an application friendly structure.

The key scoping question is therefore not whether HL7 v2 exists in the hospital. It is whether your application actually needs that feed and where translation should occur.

EHR vendors also provide proprietary APIs, platforms, and integration programmes that sit alongside standards based connectivity.

Epic is the most visible example. Its ecosystem includes MyChart, SMART on FHIR capabilities, App Orchard, and other integration pathways.

Oracle Health, MEDITECH, and athenahealth also have their own integration models, documentation, access requirements, and supported capabilities.

A vendor specific integration can expose functionality that a generic FHIR implementation does not provide. The tradeoff is increased dependency on that vendor's platform, approval process, documentation, and future product decisions.

For multi-client healthcare platforms, your architecture should separate vendor specific integration logic from the core patient experience. That makes future EHR additions easier to manage.

EHR integration decisions affect frontend scope, backend architecture, authentication, testing, vendor coordination, and delivery risk.

If your team is preparing an RFP, define the EHR vendor, required resources, authentication model, data direction, and expected clinical workflows before estimating development effort.

Epic deserves specific attention because many US healthcare organisations use it. KLAS Research reported that Epic controlled 43.7% of the US acute care hospital EHR market and 56.9% of hospital beds based on 2025 purchasing data.

That scale explains why "Epic experience" appears in so many healthcare technology proposals. It does not, however, tell you what the vendor actually knows how to implement.

According to KLAS Research, reported by Becker's Hospital Review in May 2026, Epic held 43.7% of the US acute care hospital market based on 2025 data.

Oracle Health followed at 21.9%, while MEDITECH held 14.7% of the market.

These figures matter when selecting an integration partner because EHR experience is not evenly distributed across vendors.

A team that has implemented one FHIR endpoint should not automatically describe itself as experienced with Epic. Epic projects can involve application registration, sandbox access, security review, scopes, testing, and organisational approvals.

The right procurement question is more specific: which Epic integration pathways has the team implemented, and what part of the process did it own?

Epic App Orchard is part of Epic's ecosystem for third party applications. Depending on the integration pathway, your application may need registration, testing, security review, and approval before production connectivity.

The technical build is only one part of that process. Your team also needs to understand the required application type, supported APIs, authentication approach, scopes, test environment, and production onboarding requirements.

During healthcare implementations, we have seen why submitting integration requirements early matters. Sandbox access and vendor review can become project dependencies long before the first production request is made.

A sensible delivery plan therefore treats Epic onboarding as a parallel workstream, not as a final deployment task.

"EHR integration experience" can describe very different levels of responsibility.

One agency may have embedded an existing Epic component. Another may have configured a FHIR client. A third may have handled application registration, sandbox testing, authentication, clinical scopes, production validation, and ongoing support.

Those are materially different capabilities.

When evaluating vendors, ask for a technical explanation of the integration they completed. You should understand which APIs were used, what data flowed, how authentication worked, and which vendor approvals the team handled.

That evidence gives you a more useful picture than a generic claim that the agency is "Epic experienced".

Many EHR projects do not stall because developers cannot write API requests. They stall because access, registration, scope, testing, and clinical approval were treated as administrative details.

A sandbox gives your development team an environment for testing the integration before production connectivity.

Without appropriate test access, developers may build against assumptions rather than the actual EHR behaviour. That increases the chance of rework when real authentication, resources, scopes, or response structures become available.

Sandbox access should therefore appear in the project plan alongside design and development milestones.

The same principle applies to test patient records and representative clinical scenarios. Your team needs enough realistic data variation to verify how the interface behaves when information is missing, delayed, duplicated, or returned in unexpected combinations.

Our Herexa Health integration case study provides a practical example of how healthcare platform work requires attention to integration dependencies alongside application development.

Application registration identifies your software to the EHR environment and establishes how the application is permitted to connect.

The process can involve application details, redirect URLs, authentication configuration, requested scopes, technical documentation, security information, and testing requirements.

One common mistake is completing application registration after the application has already been built. That reverses the dependency.

Your integration team should identify the registration requirements before finalising authentication and environment architecture. Changes to redirect URLs, scopes, or authentication assumptions can otherwise create avoidable rework.

A request to read patient data is also a request to define what your application is allowed to access.

That makes clinical scope an important product decision. A dashboard showing appointment information has different requirements from one displaying medications, observations, diagnoses, or clinical documents.

During healthcare implementations, scope discussions work best when product, clinical, security, and engineering stakeholders review the intended data together.

Start with the smallest set of resources required for the patient journey. Expanding access later is usually easier than designing around excessive permissions from the beginning.

The choice between an embedded application and a standalone portal affects more than branding. It determines where the patient experience lives, how much functionality your team owns, and how tightly the product depends on the EHR interface.

Epic reports more than 195 million active MyChart users, while the 2026 market reporting supplied for this brief places activated MyChart accounts above 200 million.

That scale matters because patients may already have an established EHR connected experience. Your project needs a clear reason to introduce another interface.

An embedded SMART on FHIR application can make sense when the healthcare organisation wants functionality that operates closely within an existing EHR workflow.

The application can use SMART on FHIR authentication and approved data access while providing a focused experience for a defined workflow.

This approach can reduce the need to recreate every EHR function. It works particularly well when clinicians or staff need the new capability while remaining within their existing environment.

The tradeoff is that your application must work within the host EHR's technical and user experience constraints.

A standalone patient portal makes more sense when the organisation wants a distinct digital experience rather than an extension of the EHR interface.

Your application can control navigation, content, branding, onboarding, patient education, forms, scheduling workflows, and other patient facing features.

FHIR can then provide selected clinical information without forcing the entire experience to mirror the EHR.

While building patient portals, we have seen the embedded versus standalone decision work best when teams first map the patient journey. The technical architecture follows that product decision, not the other way around.

For context, our comparison of patient portals and standard websites explains why a patient portal should be treated as a functional application rather than simply a more sophisticated website.

A standalone portal gives your team more control, but it also creates more responsibility.

You must maintain authentication, data presentation, error handling, accessibility, security controls, integration monitoring, and compatibility as the EHR changes.

An embedded approach can reduce some of that surface area, but it introduces stronger dependency on the host platform.

The right choice depends on the experience you need to own. Do not select an architecture simply because one integration method appears technically easier during the initial proposal.

An EHR connection changes the security boundary of your application. Protected Health Information can move between the EHR, your application, authentication services, databases, logs, and other integrated systems.

That means compliance cannot stop at the website's privacy policy or hosting environment.

A Business Associate Agreement defines responsibilities when a business associate handles Protected Health Information on behalf of a covered entity.

Your legal and compliance teams should determine which parties require agreements based on the actual data flows and service relationships.

The important technical question is where PHI travels. Map the EHR, integration layer, application services, storage, logging systems, analytics, support tools, and other third parties before approving the architecture.

Your HIPAA compliant website development approach should account for the integration layer rather than treating the EHR connection as an isolated API task.

Authentication does not end when the user successfully signs in.

Tokens expire. Sessions end. Refresh behaviour varies by implementation. Applications also need to handle failed requests without exposing sensitive information to users or client side logs.

Across recent compliance projects, we have focused on keeping token handling separate from presentation logic and making expiry behaviour predictable.

Your architecture should define where tokens live, how expiration is detected, how reauthentication occurs, and what happens when an API request fails midway through a patient workflow.

Audit logging provides traceability around sensitive integration activity.

A useful integration log should allow your team to determine who initiated a request, when it occurred, which resource was accessed, and whether the request succeeded or failed.

Logs themselves can contain sensitive information, so logging everything is not automatically safer.

The design should distinguish between useful audit metadata and unnecessary clinical content. Your security team should also define retention, access, monitoring, and review requirements.

Before approving an EHR connected healthcare website or patient portal, confirm the following:

A strong RFP should require the integration partner to answer these questions before providing a final delivery estimate.

EHR integration should be treated as an architectural workstream, not a final API connection added after the website is built.

FHIR R4 provides a strong foundation for new patient facing integrations, while HL7 v2 and vendor specific APIs remain relevant where existing hospital systems require them. Epic also deserves specific planning because its market position makes Epic connectivity a common requirement for healthcare web projects.

The most important procurement decision is therefore not whether an agency claims EHR experience. It is whether the team can explain the integration method, data scope, authentication model, vendor onboarding process, security architecture, and long term maintenance responsibility.

When those decisions are made early, your development estimate becomes more realistic and your delivery team has fewer unknowns to absorb later.
